Non‑Operational, System A is Menu Selected, but Faulted

Auto Switch Off
A		B
Green	Select	Off
Red/Gray	Ready	Green/Gray
Off	Active	Off

Both Active lights are off indicating that no operation is possible. The reason is that system A has faulted and software switch in this menu has disabled B. However, system B is ready to use.

Action

Set Auto Switch on. System B automatically switches to active.

Use the Radar Status Menu on system A to determine the fault.
