TS playback from a separate archive host to an RVP10

Figure 1. TS playback from a separate archive host

This is the recommended mode of operation.

In this example, the TS Switch is set to write data from the tsarchive to the TS API. tsexport sends these through a UDP broadcast over the network to an RVP10 for processing.

The diagram for the corresponding RVP10 would be identical to the one shown in this example, except the TS Switch would be set to write data from the tsimport process.

Utility settings

RVP10:

TS Switch: Network
TS Archive: N/A

Archive host:

TS Switch: Local Archive
TS Archive: Play
